21 Rope & Hawsers

WE CAN OFFER CERTIFICATE:（CCS）、德國（GL）、美國（ABS）、英國（LR）、挪威（DNV）、法國（BV）

Double Braided Hawsers 雙索編織纜繩

Features
With the unique woven structure, sophisticated technologies, the overall performances of the ropes have reached over 15. The ropes, marked with low elongation, flexible, strong and wear resistant and convenient for operation, are well received both inside and outside the country.
Application
Mainly applied in warships, ocean-going ships, ocean transportation, on-water oilfield, mine operation, fishery, etc.

Outer Braided Cover:Nylon 尼龍
Inner Braided Core: Nylon 尼龍

Specification			Polymide fiber(nylon)
CODE	SIZE		Linear density (Ktex)	Breaking Strength (daN)
CODE	Diam. ?mm	Cir. inch	Linear density (Ktex)	Breaking Strength (daN)
210731	40	5	932	38300
210732/210733	44	51/2	1136	47300
210734	48	6	1340	56000
210734	52	61/2	1568	61300
210735	56	7	1820	67500
210736	60	71/2	2090	79100
210737	64	8	2386	92300
210738	72	9	3022	118300
210739/210740	80	10	3730	142100
210741/210742	88	11	4500	187200
210743	96	12	5364	200400
210744	104	13	6320	231700
	112	14	7275	268400

Outer Braided Cover: Polypropylene
Inner Braided Cover: Polypropylene

Specification			Polypropylene Filament
CODE	SIZE		Linear density (Ktex)	Breaking Strength (daN)
CODE	Diam. ?mm	Cir. inch	Linear density (Ktex)	Breaking Strength (daN)
210831	40	5	750	23100
210832/210833	44	51/2	910	29100
210834	48	6	1068	34600
210834	52	61/2	1273	39700
210835	56	7	1454	43900
210836	60	71/2	1705	50300
210837	64	8	1910	57450
210838	72	9	2430	70410
210839/210840	80	10	3000	85700
210841/210842	88	11	3640	106100
210843	96	12	4320	123100
210844	104	13	5050	142500
	112	14	5864	163400

Outer Braided Cover: Polyester(Tetoron) 特多龍
Inner Braided Cover: Nylon 尼龍

Specification			Polyester/Nylon
CODE	SIZE		Linear density (Ktex)	Breaking Strength (daN)
CODE	Diam. ?mm	Cir. inch	Linear density (Ktex)	Breaking Strength (daN)
210931	40	5	1045	40700
210932/210933	44	51/2	1273	48200
210934	48	6	1500	58900
210935	52	61/2	1795	70600
210935	56	7	2181	77300
210936	60	71/2	2432	86400
210937	64	8	2730	98000
210938/210939	72	9	3500	132100
210940	80	10	4320	153400
210941/210942	88	11	5140	181400
210943	96	12	7180	210000
210944	104	13	8500	241300
	112	14	9545	268000

Hign Modulus Polyethylene Fibre 8-Strand Rope 高系數(shù)化織8股纜繩（HP 纜繩）

Features
The strength of high-performance polyethylene filaments is the strongest of the world, being up to 15 times of that of steel ropes and with the elongation extremely low. Thus, it can match steel ropes in terms of break strength and elongation. The ropes are resistant to ultraviolet radiation, seawater, acid and alkali, fatigue and weathering, extending the service life.

Specification			Hign Modulus Polyethylene Fibre 8-Strand Rope
CODE	SIZE		Linear density (Ktex)	Breaking Strength (daN)
CODE	Diam. ?mm	Cir. inch	Linear density (Ktex)	Breaking Strength (daN)
211123	32	562	136	62400
211124	36	712	173	81200
211125	40	868	210	92400
211126	44	955	231	102100
211127	48	1137	275	124600
211129	56	1547	374	176000
211131	64	2021	488	235800
211132	72	2598	628	287500
211134	80	3195	773	342500
211135	88	4450	1070	423000
211136	96	5700	1379	503500
	110	7930	1920	786500

Atlas Mooring Rope 6-strand Cross-laid ?6股交織Atlas纜繩

It is manufactured in a special technology, and has very high performances of wear resistance, which is over 1 time higher than the general cables of chemical fibers. This plus the advantages in the resistance to sea water, chemicals, ultraviolet radiation and high temperature, the cable has been widely used in ships and hauling.
Application
Mainly applied in ocean transportation, ship making, military industry, oil exploration, port operation and other fields.

Specification			Atlas Mooring Rope 6-strand Cross-laid
CODE	SIZE		Linear density (Ktex)	Breaking Strength (daN)
CODE	Diam. ?mm	Cir. inch	Linear density (Ktex)	Breaking Strength (daN)
	28	31/2	509	19470
	32	4	661	23450
	36	41/2	840	29700
211101	40	5	1040	33000
211102	44	51/2	1260	42500
211103	48	6	1490	50800
211104	52	61/2	1740	54200
211105	56	7	2030	65700
	60	71/2	2320	71300
211106	64	8	2650 <,><!--,-->	80400
211109	72	9	3350	107800
	80	10	4140	128700
	88	11	5010	145600
	96	12	5960	174300
	104	13	6990	210800
	112	14	8110	234700

3-Strand Polyropylene Mono-Filament Rope 3股單絲化學(xué)織維繩

Specification			3-Strand Polyropylene Mono-Filament Rope
CODE	SIZE		Linear density (Ktex)	Breaking Strength (daN)
CODE	Diam. ?mm	Cir. inch	Linear density (Ktex)	Breaking Strength (daN)
	4	1/2	1.7	230
	6	3/4	3.9	539
210251	8	1	6.9	941
210253	10	11/4	10.8	1400
210254	12	11/2	15.5	1990
210255	14	13/4	21.0	2740
210256	16	2	27.5	3430
210257	18	21/4	35.0	4370
210258	20	21/2	43.0	5270
210259	22	23/4	52.0	6370
210260	24	3	62.0	7450
210262	28	31/2	85.0	9900
210264	32	4	110.0	12600
210266	36	41/2	140.0	15800
210268	40	5	170.0	19100
	44	51/2	210.0	23000
	48	6	245.0	26700

8-Stand Polypropylene Mono-Filament Hawsers 8股單絲化學(xué)織維繩

Specification			8-Stand Polypropylene Mono-Filament Hawsers
CODE	SIZE		Linear density (Ktex)	Breaking Strength (daN)
CODE	Diam. ?mm	Cir. inch	Linear density (Ktex)	Breaking Strength (daN)
	20	21/2	195	8800
	24	3	280	11130
	28	31/2	368	13700
	32	4	486	16560
	36	41/2	600	19600
	40	5	740	23200
	44	51/2	886	29300
210351	48	6	1040	33520
210353	52	61/2	1220	38650
210355	56	7	1430	44240
210356	60	71/2	1660	50360
210357	64	8	1886	58410
210359/210360	72	9	2360	72960
210363/210364	80	10	2910	86720
210366	88	11	3527	103820
210367	96	12	4180	121000
210370	104	13	4950	143560
	112	14	5730	164380
	120	15	6540	187200
	128	16	7410	205830

3-Strand Vinylon Rope (Kuremona Rope) 3股樹脂類繩

Specification			維尼綸繩 VINYLON（KUROLOM KS）
CODE	SIZE		WEIGHT (kg/220m)	MBL (kgs or Tons)
CODE	Diam. ?mm	Cir. inch	WEIGHT (kg/220m)	MBL (kgs or Tons)
	?4	1/2	? ?2.20	? ? ? ?150kgf
	?6	3/4	? ?5.00	?330
211221	?8	1	? ?8.80	?560
211223	10	1-1/4	?13.60	?950
211224	12	1-1/2	?19.80	1370
211225	14	1-3/4	?26.40	1830
211226	16	2	?35.20	? ? ?2.34
211227	18	2-1/4	?44.00	?2.92
211228	20	2-1/2	?53.00	?3.55
211229	22	2-3/4	?64.90	?4.24
211230	24	3	?78.00	?5.00
211231	26	3-1/4	?91.00	?5.80
211232	28	3-1/2	106.00	?6.64
211233	30	3-3/4	120.00	?7.60
211234	32	4	136.00	?8.51
	36	4-1/2	173.00	10.60
	40	5	213.00	12.90
	44	5-1/2	258.00	15.30
	48	6	306.00	18.00
	52	6-1/2	359.00	21.10

3-Stand Polyethylene Tiger Rope ?3股虎斑繩

Specification			3-Strand Polyropylene Mono-Filament Rope
CODE	SIZE		Linear density (Ktex)	Breaking Strength (daN)
CODE	Diam. ?mm	Cir. inch	Linear density (Ktex)	Breaking Strength (daN)
	4	1/2	6	214
211351	6	3/4	17	601
211352	8	1	30	1060
211353	10	11/4	48	1560
211354	12	11/2	70	2210
211355	14	13/4	95	3050
211356	16	2	127	3770
211358	20	21/4	195	5800
211359	22	23/4	236	6900
211360	24	3	281	8130
	28	31/2	386	10710
	32	4	500	13600
	36	41/2	640	16900
	40	5	780	20500
	44	51/2	932	24700
	48	6	1114	29600
	52	61/2	1295	33150
	56	7	1432	37840

Signal Halyards 信號旗繩

Polypropylene
CODE	SIZE
CODE	Diam. ?mm	Cir. inch
211301	3/4”/6mm	1/2
211302	1”/8mm	3/4

Vinylon
CODE	SIZE
CODE	Diam. ?mm	Cir. inch
211311	3/4”/6mm	1/2
211312	1”/8mm	3/4

Cotton
CODE	SIZE
CODE	Diam. ?mm	Cir. inch
211306	3/4”/6mm	1/2
211307	1”/8mm	3/4

Nylon
CODE	SIZE
CODE	Diam. ?mm	Cir. inch
211316	3/4”/6mm	1/2
211317	1”/8mm	3/4

Log Line測速繩

Polypropylene
CODE	SIZE
CODE	Diam. ?mm	Cir. inch
211321	3/4”/6mm	1/2
211322	1”/8mm	3/4

Vinylon
CODE	SIZE
CODE	Diam. ?mm	Cir. inch
211331	3/4”/6mm	1/2
211332	1”/8mm	3/4

Cotton
CODE	SIZE
CODE	Diam. ?mm	Cir. inch
211326	3/4”/6mm	1/2
211327	1”/8mm	3/4

Nylon
CODE	SIZE
CODE	Diam. ?mm	Cir. inch
211336	3/4”/6mm	1/2
211337	1”/8mm	3/4

Seizing Twine

CODE	MATERIAL	DIAM	UNIT
211421	polypropylene	3	2.5kgs/BALL
211422	manila	3	2.5kgs/BALL

Siezing Wire

Galvanized

Silk Wire

CODE	Diam.mm	STD.coil	CODE	Diam.mm	STD.coil
211451	2	10 kgs	211455	2	100mtrs
211453	4	10 kgs	211457	4	100mtrs
